RGT-560F Light Steel Villa Keel Forming Machine

RGT-560F Light Steel Villa Keel Forming Machine

السعر بعد الخصم$0.00

السعر المذكور هو دفعة مقدمة فقط . قد يختلف السعر النهائي بناءً على متطلباتك وخياراتك الخاصة. تواصل معنا للحصول على عرض سعر مخصص.

RGT-560F Light Steel Villa Keel Forming Machine

  • Precision Framing: Produces light steel villa keels with ±0.5mm accuracy
  • High-Speed Production: 15-25 meters/minute operation
  • Multi-Profile Capacity: Forms C/U channels, tracks, and studs in one system
  • Smart Control: PLC with pre-programmed villa construction profiles
  • Energy Efficient: Servo-driven system reduces power consumption by 35%
Material Thickness: 0.6-2.0mm | Profile Width: 50-150mm | Power: 45kW

Technical Specifications

Parameter Specification
Model Number RGT-560F
Production Speed 15-25 m/min (adjustable)
Material Thickness 0.6-2.0mm (galvanized steel, aluminum-zinc alloy)
Profile Types C-channels, U-tracks, studs, joists
Profile Width 50-150mm
Dimensional Accuracy ±0.5mm
Control System PLC with 12" touchscreen and 50+ profile memory
Machine Dimensions 14000×2500×2000mm (L×W×H)

Advanced Features

  • Villa-Specific Tooling: Precision dies optimized for light steel construction
  • Automatic Notching: Integrated punching for assembly points
  • Smart Measurement: Laser-guided length cutting system
  • Quick-Change System: Profile changeover in under 10 minutes
  • Dust Extraction: Built-in system for clean operation
  • Safety Systems: Light curtains and emergency stops

Production Process

  1. Material Loading: Automatic decoiler with tension control
  2. Precision Forming: 14-stage progressive roll forming
  3. Notching/Punching: Automatic hole creation for assembly
  4. Cutting: Servo-controlled flying cutoff
  5. Output: Automatic stacking with protective separators

Villa Construction Profiles

Component Profile Type Standard Sizes
Wall Studs C-channel 75mm, 90mm, 120mm
Floor Joists U-channel 150mm, 200mm, 250mm
Roof Trusses Custom angles 30°-60° configurations
Track Systems U-track Match corresponding stud sizes

Available Options

Automatic Marking Component identification printing
3D Simulation Virtual profile preview
Robotic Stacking Automated palletizing system
Remote Monitoring Production data tracking
Anti-Corrosion Coating In-line protective treatment

Operational Benefits

  • Construction-Ready: Produces complete villa framing systems
  • Precision Engineering: Ensures perfect component fit
  • Reduced Labor: Automated production minimizes manpower
  • Material Savings: Optimized nesting reduces waste
  • Global Certifications: CE, ISO 9001:2015 compliant
