RGT-642F Coil-fed Series GRC/RBC Coil-fed Laser Cutting Machine
السعر المذكور هو دفعة مقدمة فقط . قد يختلف السعر النهائي بناءً على متطلباتك وخياراتك الخاصة. تواصل معنا للحصول على عرض سعر مخصص.
يرجى العلم أن السعر المذكور هو دفعة مقدمة فقط. قد يختلف السعر النهائي للجهاز بناءً على متطلباتك الخاصة وتكويناتك وميزاتك الاختيارية. بمجرد استلامنا لاحتياجاتك المفصلة، سنقدم لك عرض سعر شامل. تواصل معنا للحصول على عرض سعر مخصص.
اتصل بنا للحصول على كتالوجات المنتجات غير المحملة
الشراء المباشر: (7-10 أيام)
التخصيص: (8-12 يومًا)
RGT-642F Coil-fed Series GRC/RBC Coil-fed Laser Cutting Machine
- Coil-fed efficiency: Continuous processing without sheet loading downtime
- Dual-laser technology: Single/dual head dynamic cutting capability
- Integrated marking: Laser cutting and marking in one operation
- Zero waste production: Dynamic cutting optimization minimizes material waste
- Smart automation: QR code task management and heat equalization
Performance Improvement vs Traditional Systems
Continuous coil-fed operation eliminates loading time
±0.05mm/m positioning accuracy
Reinforced structure for continuous operation
Advanced diagnostics and preventive maintenance
Technical Specifications
| Model Series | RGT-642F GRC/RBC Series |
|---|---|
| Processing Area (L×W) | 6500×1680mm Models: 3015/4015/6018/8018/12028 |
| Max Positioning Speed | 120m/min (X/Y axis simultaneous) |
| Positioning Accuracy | ±0.05mm/m |
| Repeatability | ±0.08mm/m |
| Laser Power Options | 3000W-12000W (depending on model) |
| Cutting Head Options | Single/Dual Head | Dynamic/Static Cutting |
| Coil Capacity | Up to 10 tons (model dependent) |
| Control System | Advanced CNC with AI optimization |
Technical Advantages
Single/Dual Laser Dynamic Cutting
Flexible configuration for different production needs
Double-headed Synchronous Cutting
Complete complex tasks in single process cycle
Residue Crushing Function
Automatic scrap processing for easy recycling
QR Code Task Management
Scan codes for automatic job setup and heat management
Integrated Laser Marking
Cutting and marking in one continuous operation
Zero Waste Production
Dynamic cutting optimization eliminates material waste
Model Variations
- CRC6018: Integrated laser marking and cutting system
- CRC6029: Advanced non-destructive cutting technology
- GRC Series: General purpose coil-fed cutting
- RBC Series: High-speed precision cutting
- Custom Models: Tailored solutions for specific industries
Product Features
- Easier Recycling: Residual material crushing and recovery system
- Optimal Multitasking: Simultaneous cutting and processing operations
- Adversion-destructive Cutting: Non-destructive plate processing technology
- Dynamic Cutting Window: Zero waste material utilization
- Heat Equalization: Smart thermal management through QR code scanning
- Prevent Sheet Processing: Eliminates traditional sheet handling
Industrial Applications
Automotive Industry
High-volume body panels and structural components
Electrical Enclosures
Continuous production of cabinet and box components
Construction Materials
Structural sections and building components
Appliance Manufacturing
Household appliance panels and parts
Material Capability
- Coil Steel: 0.5-6.0mm thickness
- Stainless Steel: 0.5-4.0mm
- Aluminum Coil: 0.5-3.0mm
- Galvanized Steel: 0.5-5.0mm
- Color Coated Coils: 0.3-2.0mm
حدِّد الخيارات
هل أنت مستعد لأتمتة RGT-642F Coil-fed Series GRC/RBC Coil-fed Laser Cutting Machine الخاص بك؟
اتصل بشركة Rolangear Machinery اليوم للحصول على عرض أسعار أو خيارات التخصيص أو استشارة مجانية.
