RGE Series Servo Press Machines
Precision C-Frame Single Crank Servo Presses by Rolangear
Advanced Servo Press Technology
The RGE Series Servo Press combines precision engineering with intelligent control systems for superior metal forming performance. With fully programmable operation and energy-efficient design, these presses deliver unmatched flexibility and productivity.
Servo Press Advantages
Precision Control
Programmable stroke height and performance with real-time monitoring of motor torque, crankshaft angle, and displacement.
Energy Efficient
Reduces energy consumption by up to 30% compared to traditional presses through optimized drive solutions.
Flexible Operation
Multiple performance modes including crankshaft, multi-link, pressure maintaining, and free programming modes.
Reduced Maintenance
Simplified mechanical design with fewer wear parts compared to conventional presses.
Technical Specifications
| Model | RGE-25 | RGE-35 | RGE-45 | RGE-60 | RGE-80 | RGE-110 |
|---|---|---|---|---|---|---|
| Nominal Pressure (kN) | 250 | 350 | 450 | 600 | 800 | 1100 |
| Stroke Length (mm) | 70 | 80 | 100 | 120 | 150 | 180 |
| Speed (SPM) | 1-120 | 1-100 | 1-90 | 1-70 | 1-60 | 1-55 |
| Max Die Height (mm) | 200 | 235 | 265 | 310 | 340 | 360 |
| Die Adjustment (mm) | 50 | 55 | 60 | 70 | 80 | 80 |
| Bolster Plate (L×W mm) | 680×300 | 800×400 | 850×450 | 900×500 | 1000×550 | 1150×600 |
| Model | RGE-125 | RGE-160 | RGE-200 | RGE-250 | RGE-315 |
|---|---|---|---|---|---|
| Nominal Pressure (kN) | 1250 | 1600 | 2000 | 2500 | 3150 |
| Stroke Length (mm) | 180 | 180 | 200 | 220 | 250 |
| Speed (SPM) | 1-50 | 1-45 | 1-40 | 1-40 | 1-35 |
| Max Die Height (mm) | 360 | 420 | 460 | 500 | 500 |
| Die Adjustment (mm) | 80 | 100 | 110 | 120 | 120 |
| Bolster Plate (L×W mm) | 1150×600 | 1250×800 | 1400×820 | 1500×850 | 1500×850 |
Advanced Control Features
HMI Interface
- Moving curve programming (8 modes)
- Production state monitoring
- Real-time performance data
- Dies data management
Performance Modes
- Crankshaft mode
- Multi-link mode
- Pressure maintaining mode
- Free programming mode
Special Functions
- Instant energy release control
- Low-speed blanking near BDC
- Fine tuning with hand wheel
- Feeding device integration
RGE Series Benefits
Improved Quality
Precise control extends die life and improves part consistency with optimized forming cycles.
Higher Productivity
Faster return stroke and programmable operation significantly increase output rates.
Reduced Noise
Special modes minimize operational noise for better working environment.
Flexible Production
Quick changeover between jobs with programmable settings for different applications.
