RGT-502F Automatic Toilet Roll Rewinding Production Line
El precio indicado es solo un depósito . El precio final puede variar según sus requisitos y opciones. Contáctenos para obtener una cotización personalizada. 40 mini
Tenga en cuenta que el precio indicado es solo un depósito. El precio final de la máquina puede variar según sus requisitos específicos, configuraciones y características opcionales. Una vez que recibamos sus necesidades detalladas, le proporcionaremos un presupuesto completo. No dude en contactarnos para obtener una oferta personalizada.
Contáctanos para los catálogos de productos no subidos
Compra directa: (7-10 días)
Personalizar: (8-12 días)
RGT-502F Automatic Toilet Roll Rewinding Production Line
- Continuous operation: Non-stop production for maximum efficiency
- Wide compatibility: Handles jumbo rolls from 2000mm to 3000mm width
- Precision rewinding: Consistent tension control for perfect rolls
- High-speed production: Optimized for large-scale toilet paper manufacturing
- Modular design: Customizable configuration for different product requirements
Product Overview
The RGT-502F Automatic Toilet Roll Rewinding Production Line is designed for high-volume, continuous production of premium quality toilet paper rolls. This complete system features advanced tension control, precision slitting, and automatic core insertion to deliver perfectly wound toilet rolls with exceptional efficiency.
Non-Stop Production
Continuous operation with automatic splicing for uninterrupted production
Precision Slitting
Multi-blade slitting system for consistent roll widths
Automatic Core Handling
Integrated core insertion and ejection system
Key Features
- Fully automated production line from jumbo roll to finished product
- Advanced tension control system for uniform roll density
- Touchscreen HMI with production monitoring and diagnostics
- Energy-efficient motors and drives
- Quick-changeover design for different product specifications
- Safety interlocks and emergency stop systems
Technical Specifications
| Model | RGT-502F |
|---|---|
| Jumbo Roll Width | 2000-3000mm (customizable) |
| Production Speed | Up to 600m/min (depending on configuration) |
| Finished Roll Diameter | Customizable from 90mm to 130mm |
| Core Size | Standard 40mm (customizable) |
| Control System | PLC with servo motor control |
Why Choose This Model?
The RGT-502F Automatic Toilet Roll Rewinding Production Line represents the latest advancement in toilet paper manufacturing technology. Designed for continuous, high-volume production, this system delivers exceptional efficiency and product consistency. With its wide compatibility for different jumbo roll sizes and customizable finished product specifications, it offers manufacturers unmatched flexibility. The precision tension control ensures perfect roll formation every time, while the modular design allows for easy adaptation to different production requirements. This production line is the ideal solution for manufacturers looking to maximize output while maintaining the highest quality standards in toilet paper production.
Mount Sun Technology: Incorporating our proprietary Mount Sun tension control system for unparalleled rewinding precision and consistency.
Elige opciones
¿Está listo para automatizar su RGT-502F Automatic Toilet Roll Rewinding Production Line ?
Comuníquese con Rolangear Machinery hoy para obtener una cotización, opciones de personalización o una consulta gratuita.
