RGGT Series Knuckle Joint High-Speed Presses
Precision High-Speed Stamping Machines by Rolangear
Ultra-High Speed Precision Pressing
The RGGT Series Knuckle Joint Press delivers exceptional precision at speeds up to 2000 SPM. Featuring advanced knuckle joint mechanism and dynamic balancing, these presses are engineered for demanding high-volume production.
Technical Specifications
| Model | RGGT-15H | RGGT-30 | RGGT-40 | RGGT-60 |
|---|---|---|---|---|
| Capacity (kN) | 150 | 300 | 400 | 600 |
| Stroke Length (mm) | 10 | 20-32 | 20-32 | 20-32 |
| Speed (SPM) | 200-2000 | 200-1200 | 180-1000 | 100-850 |
| Die Height (mm) | 220 | 240 | 240 | 300 |
| Die Adjustment (mm) | 30 | 40 | 50 | 80 |
| Motor Power (kW) | 15 | 11 | 15 | 22 |
| Model | RGGT-80 | RGGT-125 | RGGT-150 |
|---|---|---|---|
| Capacity (kN) | 800 | 1250 | 1500 |
| Stroke Length (mm) | 20-36 | 25-36 | 30-36 |
| Speed (SPM) | 120-700 | 100-600 | 100-400 |
| Die Height (mm) | 320 | 350 | 350 |
| Die Adjustment (mm) | 80 | 80 | 80 |
| Motor Power (kW) | 30 | 37 | 37 |
Standard Features
Control System
- Inverter variable speed motor
- Electronic crank angle indicator
- Touch panel interface
- 9-digit electronic counters
Operation
- Air friction clutch/brake
- Dynamic balancer
- Pneumatic control unit
- Both hands push buttons
Safety & Maintenance
- Circulation lubrication system
- Safety door with interlock
- Misfeed detection
- Shock absorbers
RGT Series Advantages
Ultra-High Speed
Press speeds up to 2000 SPM enable maximum productivity for high-volume applications.
Precision Accuracy
Knuckle joint mechanism ensures superior bottom dead center accuracy for consistent results.
Energy Efficient
Inverter control and optimized drive system reduce power consumption without compromising performance.
Reduced Vibration
Dynamic balancer and shock absorbers minimize vibration for smooth operation and longer component life.
